Page #27 background image
Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 27
About the Switches Chapter 1
Stratix 5700 and ArmorStratix 5700 Templates
The following SDM templates are available:
•Default
Lanbase Routing
Dual IPv4 and IPv6
If you enable static routing, or if you have more than 180 IGMP groups or
multicast routes., consider using the routing template.
If you use IPv6, consider using the Dual IPv4 and IPv6 template.
You can select SDM templates for IP version 4 (IPv4) to optimize these
features.
Table 8 - Stratix 5700 and ArmorStratix 5700 Templates
Feature Memory Allocation
Default Lanbase Routing Dual IPv4 and IPv6
Unicast MAC addresses 8K 4K 7.5K
IPv4 IGMP groups + multicast
routes
0.25K 0.25K 0.25K
IPv4 unicast routes 0 4.25K 0
IPv6 multicast groups 0 0 0.375K
Directly connected IPv4 hosts 0 4K
Directly connected IPv6 addresses 0 0 0
Indirect IPv4 routes 0 0.25K
Indirect IPv6 routes 0 0 0
IPv4 policy-based routing aces 0 0
IPv4/MAC QoS aces 0.375K 0.375K 0.375K
IPv4/MAC security aces 0.375K 0.375K 0.375K
IPv6 policy-based routing aces 0 0 0
IPv6 QoS aces 0 0 0
IPv6 security aces 0 0 0.125K
