Allen-Bradley Stratix 5700 - 18-Port Gb Switches

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 467
Data Types Appendix A
18-port Gb Switches
Catalog numbers 1783-BMS12T4E2CGNK, 1783-BMS12T4E2CGP,
1783-BMS12T4E2CGL, 1783-ZMS8T8E2TGN, 1783-ZMS8T8E2TGP
PortFa1_8Utilization SINT Decimal
PortFa1_9Utilization SINT Decimal
PortFa1_10Utilization SINT Decimal
PortFa1_11Utilization SINT Decimal
PortFa1_12Utilization SINT Decimal
PortFa1_13Utilization SINT Decimal
PortFa1_14Utilization SINT Decimal
PortFa1_15Utilization SINT Decimal
PortFa1_16Utilization SINT Decimal
PortFa1_17Utilization SINT Decimal
PortFa1_18Utilization SINT Decimal
PortGi1_1Utilization SINT Decimal
PortGi1_2Utilization SINT Decimal
MajorAlarmRelay BOOL Decimal AlarmRelay:0
MulticastGroupsActive DINT Binary
Table 150 - Input Data Type (18-port Gb switches)
AB:STRATIX_5700_18PORT_GB_MANAGED:I:0
Member Name Type Default
Display Style
Valid Values
Fault DINT Binary
AnyPortConnected BOOL Decimal LinkStatus:0
PortFa1_1Connected BOOL Decimal LinkStatus:1
PortFa1_2Connected BOOL Decimal LinkStatus:2
PortFa1_3Connected BOOL Decimal LinkStatus:3
PortFa1_4Connected BOOL Decimal LinkStatus:4
PortFa1_5Connected BOOL Decimal LinkStatus:5
PortFa1_6Connected BOOL Decimal LinkStatus:6
PortFa1_7Connected BOOL Decimal LinkStatus:7
PortFa1_8Connected BOOL Decimal LinkStatus:8
PortFa1_9Connected BOOL Decimal LinkStatus:9
PortFa1_10Connected BOOL Decimal LinkStatus:10
PortFa1_11Connected BOOL Decimal LinkStatus:11
PortFa1_12Connected BOOL Decimal LinkStatus:12
Table 149 - Input Data Type (20-port Gb switches) (continued)
AB:STRATIX_5700_20PORT_GB_MANAGED:I:0
Member Name Type Default
Display Style
Valid Values
