Stratix 5410 Data Types
The following tables list module-defined data types for Stratix 5410 switches.
The tables include information for input (I) and output (O).
Table 135 - Input Data Type
AB:STRATIX_5410_28PORT_GB_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
Fault DINT Binary
AnyPortConnected BOOL Decimal LinkStatus:0
PortGi1_1Connected BOOL Decimal LinkStatus:1
PortGi1_2Connected BOOL Decimal LinkStatus:2
PortGi1_3Connected BOOL Decimal LinkStatus:3
PortGi1_4Connected BOOL Decimal LinkStatus:4
PortGi1_5Connected BOOL Decimal LinkStatus:5
PortGi1_6Connected BOOL Decimal LinkStatus:6
PortGi1_7Connected BOOL Decimal LinkStatus:7
PortGi1_8Connected BOOL Decimal LinkStatus:8
PortGi1_9Connected BOOL Decimal LinkStatus:9
PortGi1_10Connected BOOL Decimal LinkStatus:10
PortGi1_11Connected BOOL Decimal LinkStatus:11
PortGi1_12Connected BOOL Decimal LinkStatus:12
PortGi1_13Connected BOOL Decimal LinkStatus:13
PortGi1_14Connected BOOL Decimal LinkStatus:14
PortGi1_15Connected BOOL Decimal LinkStatus:15
PortGi1_16Connected BOOL Decimal LinkStatus:16
PortGi1_17Connected BOOL Decimal LinkStatus:17
PortGi1_18Connected BOOL Decimal LinkStatus:18
PortGi1_19Connected BOOL Decimal LinkStatus:19
PortGi1_20Connected BOOL Decimal LinkStatus:20
PortGi1_17Connected BOOL Decimal LinkStatus:17
PortGi1_18Connected BOOL Decimal LinkStatus:18
PortGi1_19Connected BOOL Decimal LinkStatus:19
PortGi1_20Connected BOOL Decimal LinkStatus:20
PortGi1_21Connected BOOL Decimal LinkStatus:21
PortGi1_22Connected BOOL Decimal LinkStatus:22
PortGi1_23Connected BOOL Decimal LinkStatus:23
PortGi1_24Connected BOOL Decimal LinkStatus:24
PortTe1_25Connected
or
PortGi1_25Connected
BOOL Decimal LinkStatus:25
PortTe1_26Connected
or
PortGi1_26Connected
BOOL Decimal LinkStatus:26
