Appendix A Data Types
16-port Switches
Catalog number 1783-HMS4S8E4CGN
Table 126 - Output Data Type (12-port Gb switches)
AB:STRATIX_5400_12PORT_GB_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
AllPortsDisabled BOOL Decimal DisablePort:0
PortGi1_1Disable BOOL Decimal DisablePort:1
PortGi1_2Disable BOOL Decimal DisablePort:2
PortGi1_3Disable BOOL Decimal DisablePort:3
PortGi1_4Disable BOOL Decimal DisablePort:4
PortGi1_5Disable BOOL Decimal DisablePort:5
PortGi1_6Disable BOOL Decimal DisablePort:6
PortGi1_7Disable BOOL Decimal DisablePort:7
PortGi1_8Disable BOOL Decimal DisablePort:8
PortGi1_9Disable BOOL Decimal DisablePort:9
PortGi1_10Disable BOOL Decimal DisablePort:10
PortGi1_11Disable BOOL Decimal DisablePort:11
PortGi1_12Disable BOOL Decimal DisablePort:12
Table 127 - Input Data Type (16-port switches)
AB:STRATIX_5400_16PORT_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
Fault DINT Binary
AnyPortConnected BOOL Decimal LinkStatus:0
PortGi1_1Connected BOOL Decimal LinkStatus:1
PortGi1_2Connected BOOL Decimal LinkStatus:2
PortGi1_3Connected BOOL Decimal LinkStatus:3
PortGi1_4Connected BOOL Decimal LinkStatus:4
PortFa1_5Connected BOOL Decimal LinkStatus:5
PortFa1_6Connected BOOL Decimal LinkStatus:6
PortFa1_7Connected BOOL Decimal LinkStatus:7
PortFa1_8Connected BOOL Decimal LinkStatus:8
PortFa1_9Connected BOOL Decimal LinkStatus:9
PortFa1_10Connected BOOL Decimal LinkStatus:10
PortFa1_11Connected BOOL Decimal LinkStatus:11
PortFa1_12Connected BOOL Decimal LinkStatus:12
PortFa1_13Connected BOOL Decimal LinkStatus:13
PortFa1_14Connected BOOL Decimal LinkStatus:14
