Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 401

Monitor the Switch Chapter 8

Private-to-Public Translation Diagnostics

From the Private to Public Translations dialog box for an instance, you can

view a list of IP addresses that have been changed by NAT within the last 90

seconds.

Table 111 - Private-to-Public Translation Diagnostics

Field Description

Private Displays the existing address for a device on the private subnet.

Public Displays a unique public address that represents the corresponding device on the private subnet.

Subnet Indicates whether the translation is part of a Subnet entry type.

Number of Packets Displays the number of packets that contain the translation.
