20 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Chapter 1 About the Switches
Lite Versus Full
Firmware Features
(Stratix 5700 Switches)
Some features for Stratix 5700 switches depend on whether the switches have
Full or Lite firmware. All Stratix 8000 and ArmorStratix 5700 switches have
Full firmware.
To determine the firmware type available for specific catalog numbers, see the
Stratix 5700 switch descriptions in
Table 166 on page 505.
Feature Lite Firmware Full Firmware
CIP Sync (IEEE 1588) Separate option
Resilient Ethernet Protocol (REP)
••
FlexLinks
•
Quality of Service (QoS)
•
Spanning Tree Protocol (STP), Rapid Spanning Tree
Protocol (RSTP), MST (instances)
64 128
Internet Group Management Protocol (IGMP) Snooping
with querier
••
Virtual Local Area Networks (VLANs) with trunking 64 255
EtherChannel (link aggregation)
•
Port Threshold (Storm control and traffic shaping)
•
IPv6 support
•
Access Control Lists (ACL)
•
Static and interVLAN routing
•
CIP port control and fault detection
••
MAC ID Port security
•
IEEE 802.1x security
•
TACACS+, RADIUS authentication
••
Encryption (SSH, SNMPv3, HTTPS) Separate IOS firmware available as a separate item
Port mirroring
••
Syslog
••
Broken wire detection
••
Duplicate IP address detection •
•
Simple Network Management Protocol (SNMP)
••
Smartports
••
Dynamic Host Configuration Protocol (DHCP) per port
••
Command-line interface (CLI)
••
Compatible with Cisco tools: Cisco Network Assistant
(CNA); CiscoWorks
••
EtherNet/IP (CIP) interface
••
Device-level ring (DLR) Available on specific models that are listed on page 215
