Page #30 background image
30 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Chapter 2 Get Started
Express Setup Overview
When you first install the switch, use Express Setup to perform these initial
setup tasks:
Assign the switch an initial IP address. You can then access the switch
through the IP address for more configuration.
Run the global macro to set initial configuration parameters, as
described on
page 43.
Express Setup Requirements
Multi-mode and single-mode versions of Express Setup are available depending
on your switch and IOS version:
With IOS version 15.2(4)EA3 or later, all switches use multi-mode
Express Setup, as described on
page 34.
With IOS version 15.2(4)EA or earlier, all switches use single-mode
Express Setup, as described on
page 38.
Multi-mode Express Setup enables you to configure network settings in either
Device Manager or the Studio 5000 Logix Designer® application. To configure
network settings via the Logix Designer application, you must have the Add-on
Profile (AOP) for Stratix® switches, version 11.01.xx or later.
