Appendix A Data Types
Stratix 5400 Data Types
The following tables list module-defined data types for Stratix® 5400 switches.
The tables include information for input (I) and output (O).
8-port Switches
Catalog number 1783-HMS4C4CGN
Table 121 - Input Data Types (8-port switches)
AB:STRATIX_5400_8PORT_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
Fault DINT Binary
AnyPortConnected BOOL Decimal LinkStatus:0
PortGi1_1Connected BOOL Decimal LinkStatus:1
PortGi1_2Connected BOOL Decimal LinkStatus:2
PortGi1_3Connected BOOL Decimal LinkStatus:3
PortGi1_4Connected BOOL Decimal LinkStatus:4
PortFa1_5Connected BOOL Decimal LinkStatus:5
PortFa1_6Connected BOOL Decimal LinkStatus:6
PortFa1_7Connected BOOL Decimal LinkStatus:7
PortFa1_8Connected BOOL Decimal LinkStatus:8
AnyPortUnauthorizedDevice BOOL Decimal UnauthorizedDevice:0
PortGi1_1UnauthorizedDevice BOOL Decimal UnauthorizedDevice:1
PortGi1_2UnauthorizedDevice BOOL Decimal UnauthorizedDevice:2
PortGi1_3UnauthorizedDevice BOOL Decimal UnauthorizedDevice:3
PortGi1_4UnauthorizedDevice BOOL Decimal UnauthorizedDevice:4
PortFa1_5UnauthorizedDevice BOOL Decimal UnauthorizedDevice:5
PortFa1_6UnauthorizedDevice BOOL Decimal UnauthorizedDevice:6
PortFa1_7UnauthorizedDevice BOOL Decimal UnauthorizedDevice:7
PortFa1_8UnauthorizedDevice BOOL Decimal UnauthorizedDevice:8
AnyPortThreshold BOOL Decimal ThresholdExceeded:0
PortGi1_1Threshold BOOL Decimal ThresholdExceeded:1
PortGi1_2Threshold BOOL Decimal ThresholdExceeded:2
PortGi1_3Threshold BOOL Decimal ThresholdExceeded:3
PortGi1_4Threshold BOOL Decimal ThresholdExceeded:4
PortFa1_5Threshold BOOL Decimal ThresholdExceeded:5
PortFa1_6Threshold BOOL Decimal ThresholdExceeded:6
PortFa1_7Threshold BOOL Decimal ThresholdExceeded:7
PortFa1_8Threshold BOOL Decimal ThresholdExceeded:8
AllPortsUtilization SINT Decimal
PortGi1_1Utilization SINT Decimal
PortGi1_2Utilization SINT Decimal
