Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 461
Data Types Appendix A
PortFa1_6UnauthorizedDevice BOOL Decimal UnauthorizedDevice:6
PortFa1_7UnauthorizedDevice BOOL Decimal UnauthorizedDevice:7
PortFa1_8UnauthorizedDevice BOOL Decimal UnauthorizedDevice:8
PortFa1_9UnauthorizedDevice BOOL Decimal UnauthorizedDevice:9
PortFa1_10UnauthorizedDevice BOOL Decimal UnauthorizedDevice:10
AnyPortThreshold BOOL Decimal ThresholdExceeded:0
PortFa1_1Threshold BOOL Decimal ThresholdExceeded:1
PortFa1_2Threshold BOOL Decimal ThresholdExceeded:2
PortFa1_3Threshold BOOL Decimal ThresholdExceeded:3
PortFa1_4Threshold BOOL Decimal ThresholdExceeded:4
PortFa1_5Threshold BOOL Decimal ThresholdExceeded:5
PortFa1_6Threshold BOOL Decimal ThresholdExceeded:6
PortFa1_7Threshold BOOL Decimal ThresholdExceeded:7
PortFa1_8Threshold BOOL Decimal ThresholdExceeded:8
PortFa1_9Threshold BOOL Decimal ThresholdExceeded:9
PortFa1_10Threshold BOOL Decimal ThresholdExceeded:10
AllPortsUtilization SINT Decimal
PortFa1_1Utilization SINT Decimal
PortFa1_2Utilization SINT Decimal
PortFa1_3Utilization SINT Decimal
PortFa1_4Utilization SINT Decimal
PortFa1_5Utilization SINT Decimal
PortFa1_6Utilization SINT Decimal
PortFa1_7Utilization SINT Decimal
PortFa1_8Utilization SINT Decimal
PortFa1_9Utilization SINT Decimal
PortFa1_10Utilization SINT Decimal
MajorAlarmRelay BOOL Decimal AlarmRelay:0
MulticastGroupsActive DINT Binary
Table 145 - Input Data Type (10-port switches) (continued)
