Allen-Bradley Stratix 5700 User Manual

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 453
Data Types Appendix A
Table 136 - Output Data Type
AB:STRATIX_5410_28PORT_GB_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
AllPortsDisabled BOOL Decimal DisablePort:0
PortGi1_1Disable BOOL Decimal DisablePort:1
PortGi1_2Disable BOOL Decimal DisablePort:2
PortGi1_3Disable BOOL Decimal DisablePort:3
PortGi1_4Disable BOOL Decimal DisablePort:4
PortGi1_5Disable BOOL Decimal DisablePort:5
PortGi1_6Disable BOOL Decimal DisablePort:6
PortGi1_7Disable BOOL Decimal DisablePort:7
PortGi1_8Disable BOOL Decimal DisablePort:8
PortGi1_9Disable BOOL Decimal DisablePort:9
PortGi1_10Disable BOOL Decimal DisablePort:10
PortGi1_11Disable BOOL Decimal DisablePort:11
PortGi1_12Disable BOOL Decimal DisablePort:12
PortGi1_13Disable BOOL Decimal DisablePort:13
PortGi1_14Disable BOOL Decimal DisablePort:14
PortGi1_15Disable BOOL Decimal DisablePort:15
PortGi1_16Disable BOOL Decimal DisablePort:16
PortGi1_17Disable BOOL Decimal DisablePort:17
PortGi1_18Disable BOOL Decimal DisablePort:18
PortGi1_19Disable BOOL Decimal DisablePort:19
PortGi1_20Disable BOOL Decimal DisablePort:20
PortGi1_21Disable BOOL Decimal DisablePort:21
PortGi1_22Disable BOOL Decimal DisablePort:22
PortGi1_23Disable BOOL Decimal DisablePort:23
PortGi1_24Disable BOOL Decimal DisablePort:24
PortTe1_25Disable
or
PortGi1_25Disable
BOOL Decimal DisablePort:25
PortTe1_26Disable
or
PortGi1_26Disable
BOOL Decimal DisablePort:26
PortTe1_27Disable
or
PortGi1_27Disable
BOOL Decimal DisablePort:27
PortTe1_28Disable
or
PortGi1_28Disable
BOOL Decimal DisablePort:28

Allen-Bradley Stratix 5700 Specifications

General

Model	Stratix 5700
Port Types	RJ45, SFP
Mounting	DIN Rail or Panel Mount
Dimensions	Varies by model
Weight	Varies by model
Management	Web-based, SNMP, Command Line
Redundancy	Device Level Ring, STP, RSTP
Operating Temperature	-40°C to 70°C
Power Supply	Dual DC inputs
Input Voltage	24 VDC or 100-240 VAC
Protocols	EtherNet/IP, DLR
Security Features	SSH, HTTPS, RADIUS, TACACS+
