470 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017

Appendix A Data Types

PortFa1_6Disable BOOL Decimal DisablePort:6

PortFa1_7Disable BOOL Decimal DisablePort:7

PortFa1_8Disable BOOL Decimal DisablePort:8

PortFa1_9Disable BOOL Decimal DisablePort:9

PortFa1_10Disable BOOL Decimal DisablePort:10

PortFa1_11Disable BOOL Decimal DisablePort:11

PortFa1_12Disable BOOL Decimal DisablePort:12

PortFa1_13Disable BOOL Decimal DisablePort:13

PortFa1_14Disable BOOL Decimal DisablePort:14

PortFa1_15Disable BOOL Decimal DisablePort:15

PortFa1_16Disable BOOL Decimal DisablePort:16

PortGi1_1Disable BOOL Decimal DisablePort:19

PortGi1_2Disable BOOL Decimal DisablePort:20

Table 151 - Output Data Type (18-port Gb switches) (continued)

AB:STRATIX_5700_20PORT_GB_MANAGED:O:0

Member Name Type Default Display

Style

Valid Values

Main Page

Default Chapter2
