Appendix A Data Types
AllPortsUtilization SINT Decimal
PortFa1_1Utilization SINT Decimal
PortFa1_2Utilization SINT Decimal
PortFa1_3Utilization SINT Decimal
PortFa1_4Utilization SINT Decimal
PortFa1_5Utilization SINT Decimal
PortFa1_6Utilization SINT Decimal
PortFa1_7Utilization SINT Decimal
PortFa1_8Utilization SINT Decimal
PortFa1_9Utilization SINT Decimal
PortFa1_10Utilization SINT Decimal
PortFa1_11Utilization SINT Decimal
PortFa1_12Utilization SINT Decimal
PortFa1_13Utilization SINT Decimal
PortFa1_14Utilization SINT Decimal
PortFa1_15Utilization SINT Decimal
PortFa1_16Utilization SINT Decimal
PortFa1_17Utilization SINT Decimal
PortFa1_18Utilization SINT Decimal
PortFa1_19Utilization SINT Decimal
PortFa1_20Utilization SINT Decimal
MajorAlarmRelay BOOL Decimal AlarmRelay:0
MulticastGroupsActive DINT Binary
Table 155 - Output Data Type (20-port switches)
AB:STRATIX_5700_20PORT_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
AllPortsDisabled BOOL Decimal DisablePort:0
PortFa1_1Disable BOOL Decimal DisablePort:1
PortFa1_2Disable BOOL Decimal DisablePort:2
PortFa1_3Disable BOOL Decimal DisablePort:3
PortFa1_4Disable BOOL Decimal DisablePort:4
PortFa1_5Disable BOOL Decimal DisablePort:5
PortFa1_6Disable BOOL Decimal DisablePort:6
PortFa1_7Disable BOOL Decimal DisablePort:7
PortFa1_8Disable BOOL Decimal DisablePort:8
PortFa1_9Disable BOOL Decimal DisablePort:9
Table 154 - Input Data Type (20-port switches) (continued)
AB:STRATIX_5700_20PORT_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values

Allen-Bradley Stratix 5700 Specifications

General

Model	Stratix 5700
Port Types	RJ45, SFP
Mounting	DIN Rail or Panel Mount
Dimensions	Varies by model
Weight	Varies by model
Management	Web-based, SNMP, Command Line
Redundancy	Device Level Ring, STP, RSTP
Operating Temperature	-40°C to 70°C
Power Supply	Dual DC inputs
Input Voltage	24 VDC or 100-240 VAC
Protocols	EtherNet/IP, DLR
Security Features	SSH, HTTPS, RADIUS, TACACS+
