Allen-Bradley Stratix 5700 User Manual

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 485
Data Types Appendix A
Table 159 - Output Data Types
Tag Name Type Description
AllPortsDisable BOOL Setting this bit disables all ports on the switch.
0 = Enable
1 = Disable
PortGi1_1Disable BOOL Setting a particular bit disables that particular port.
0 = Enable
1 = Disable
PortGi1_2Disable BOOL
PortFa1_1Disable BOOL
PortFa1_2Disable BOOL
PortFa1_3Disable BOOL
PortFa1_4Disable BOOL
PortFa1_5Disable BOOL
PortFa1_6Disable BOOL
PortFa1_7Disable BOOL
PortFa1_8Disable BOOL
PortFa2_1Disable BOOL
PortFa2_2Disable BOOL
PortFa2_3Disable BOOL
PortFa2_4Disable BOOL
PortFa2_5Disable BOOL
PortFa2_6Disable BOOL
PortFa2_7Disable BOOL
PortFa2_8Disable BOOL
PortFa3_1Disable BOOL
PortFa3_2Disable BOOL
PortFa3_3Disable BOOL
PortFa3_4Disable BOOL
PortFa3_5Disable BOOL
PortFa3_6Disable BOOL
PortFa3_7Disable BOOL
PortFa3_8Disable BOOL

Allen-Bradley Stratix 5700 Specifications

General

Model	Stratix 5700
Port Types	RJ45, SFP
Mounting	DIN Rail or Panel Mount
Dimensions	Varies by model
Weight	Varies by model
Management	Web-based, SNMP, Command Line
Redundancy	Device Level Ring, STP, RSTP
Operating Temperature	-40°C to 70°C
Power Supply	Dual DC inputs
Input Voltage	24 VDC or 100-240 VAC
Protocols	EtherNet/IP, DLR
Security Features	SSH, HTTPS, RADIUS, TACACS+
