Allen-Bradley Stratix 5700 User Manual

516 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Appendix C Port Numbering
1783-MX04E 4-port (4 PoE ports) expansion module 1
2
3
4
Fa#/1
Fa#/2
Fa#/3
Fa#/4
1783-MX04T04E 8-port(4 Ethernet ports; 4 PoE ports) expansion module 1
2
3
4
5
6
7
8
Fa#/1
Fa#/2
Fa#/3
Fa#/4
Fa#/5
Fa#/6
Fa#/7
Fa#/8
1783-MX04S 4-port (4 SFP ports) expansion module 1
2
3
4
Fa#/1
Fa#/2
Fa#/3
Fa#/4
1783-MX08S 8-port (8 SFP ports) expansion module 1
2
3
4
5
6
7
8
Fa#/1
Fa#/2
Fa#/3
Fa#/4
Fa#/5
Fa#/6
Fa#/7
Fa#/8
1783-MX08T 8-port (8 Ethernet ports) expansion module 1
2
3
4
5
6
7
8
Fa#/1
Fa#/2
Fa#/3
Fa#/4
Fa#/5
Fa#/6
Fa#/7
Fa#/8
1783-MX08F 8-port (8 Ethernet ports) expansion module 1
2
3
4
5
6
7
8
Fa#/1
Fa#/2
Fa#/3
Fa#/4
Fa#/5
Fa#/6
Fa#/7
Fa#/8
Table 168 - Stratix 8000/8300 Switch and Expansion Module Port Numbering (continued)
Cat. No. Description Port Numbering on Switch Labels Port Numbering in config.txt Text File

Allen-Bradley Stratix 5700 Specifications

General

Model	Stratix 5700
Port Types	RJ45, SFP
Mounting	DIN Rail or Panel Mount
Dimensions	Varies by model
Weight	Varies by model
Management	Web-based, SNMP, Command Line
Redundancy	Device Level Ring, STP, RSTP
Operating Temperature	-40°C to 70°C
Power Supply	Dual DC inputs
Input Voltage	24 VDC or 100-240 VAC
Protocols	EtherNet/IP, DLR
Security Features	SSH, HTTPS, RADIUS, TACACS+
