Allen-Bradley Stratix 5700 User Manual

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 521
Cables and Connectors Appendix D
The following table lists the pinouts for the console port, the RJ45-to-DB-9
adapter cable, and the console device.
The following table lists the pinouts for the console port, RJ45-to-DB-25
female DTE adapter, and the console device. The RJ45-to-DB-25 female DTE
adapter is not supplied with the switch.
Table 169 - Pinouts with DB-9 Pin
Switch Console Port (DTE) RJ45-to-DB-9 Terminal Adapter Console Device
Signal DB-9 Pin Signal
RTS 8 CTS
DTR 6 DSR
TxD 2 RxD
GND 5 GND
GND 5 GND
RxD 3 TxD
DSR 4 DTR
CTS 7 RTS
Table 170 - Pinouts with DB-25 Pin
Switch Console Port (DTE) RJ45-to-DB-25 Terminal Adapter Console Device
Signal DB-25 Pin Signal
RTS 5 CTS
DTR 6 DSR
TxD 3 RxD
GND 7 GND
GND 7 GND
RxD 2 TxD
DSR 20 DTR
CTS 4 RTS

Allen-Bradley Stratix 5700 Specifications

General

Model	Stratix 5700
Port Types	RJ45, SFP
Mounting	DIN Rail or Panel Mount
Dimensions	Varies by model
Weight	Varies by model
Management	Web-based, SNMP, Command Line
Redundancy	Device Level Ring, STP, RSTP
Operating Temperature	-40°C to 70°C
Power Supply	Dual DC inputs
Input Voltage	24 VDC or 100-240 VAC
Protocols	EtherNet/IP, DLR
Security Features	SSH, HTTPS, RADIUS, TACACS+
