Configuration Value
Dipswitch 8 (Drain)*
Dipswitch 7 (Electric Heat) **
Dipswitch 6 (Steam Heat)**
Dipswitch 5 (Unused)
Dipswitch 4 (Unused)
Dipswitch 3 (Payment System)**
Dipswitch 2 (Unused)
Dipswitch 1 (Volt Supply) ***
144 ON OFF OFF ON OFF OFF OFF OFF
145 ON OFF OFF ON OFF OFF OFF ON
146 ON OFF OFF ON OFF OFF ON OFF
147 ON OFF OFF ON OFF OFF ON ON
148 ON OFF OFF ON OFF ON OFF OFF
149 ON OFF OFF ON OFF ON OFF ON
150 ON OFF OFF ON OFF ON ON OFF
151 ON OFF OFF ON OFF ON ON ON
152 ON OFF OFF ON ON OFF OFF OFF
153 ON OFF OFF ON ON OFF OFF ON
154 ON OFF OFF ON ON OFF ON OFF
155 ON OFF OFF ON ON OFF ON ON
156 ON OFF OFF ON ON ON OFF OFF
157 ON OFF OFF ON ON ON OFF ON
158 ON OFF OFF ON ON ON ON OFF
159 ON OFF OFF ON ON ON ON ON
160 ON OFF ON OFF OFF OFF OFF OFF
161 ON OFF ON OFF OFF OFF OFF ON
162 ON OFF ON OFF OFF OFF ON OFF
163 ON OFF ON OFF OFF OFF ON ON
164 ON OFF ON OFF OFF ON OFF OFF
165 ON OFF ON OFF OFF ON OFF ON
166 ON OFF ON OFF OFF ON ON OFF
167 ON OFF ON OFF OFF ON ON ON
168 ON OFF ON OFF ON OFF OFF OFF
Table 35 continues...
Machine Diagnostic Functions
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
147 Part No. F8615401ENR4
