Audio Signal AUdio
This option allows the owner to program when the signal will
sound.
The occasions when a signal may sound during operation are list-
ed below:
• End of Cycle Signal - By default, the signal is turned off. If
turned on, the signal will sound for three (3) seconds at the
end of a cycle.
• Keypad Depression Signal - By default, this signal is turned
on and will sound for a quarter of a second. This signal will
sound each time a keypad is pressed.
• Coin Input/Card Insertion Signal - By default, this signal is
turned on and will sound for a quarter of a second each time a
coin or card is entered.
• Remove Card Signal (Card Models Only) - By default, this
signal is turned on and will sound one (1) second on and one
(1) second off when the control is prompting for card remov-
al.
• Signal for Start - By default, this signal is turned on and will
sound one (1) second on and one (1) second off for 10 sec-
onds after vend price has been satisfied.
1. Control must be in Manual Mode. Refer to Entering the Man-
ual Mode.
2. Press the Delicates Bulky (∧) or the Cold (∨) keypad until
Prog appears in the display. Press the START (enter) keypad
and AtS 1 will appear in the display.
3. Press the Delicates Bulky (∧) or the Cold (∨) keypad to scroll
through the programmable options until AUdio appears in the
display.
4.
When AUdio appears in the display press the START (enter)
keypad. A number will appear in the display. This number
corresponds to the current Audio Signal Programming Value.
5. Locate the desired number in the first column of Table 1.
6. Press the Delicates Bulky (∧) or the Cold (∨) keypad to in-
crease or decrease the current number until correct.
For Example: A owner might wish to have the signal sound only
when a keypad is pressed. Entering the number 1 in step5 would
turn off all the options except KEYPAD. In this instance, the sig-
nal would sound only when a keypad is pressed.
NOTE: To go back to the current programmable op-
tion without changing the value of the active digit,
press the Warm (<) keypad.
7. Press the START (enter) keypad when the correct value ap-
pears in the display. The new value is saved and the next op-
tion will appear in the display.
How to Read Audio Signal Chart
To determine the correct number required to program the Audio
Signal, use the following chart. The Signal Value column con-
tains the number required in step 6. The other columns corre-
spond to individual options.
Each column of options contains a unique combination of the
words ON and OFF that indicates if that column’s option is
turned on or off when the Signal Value is entered. Select the de-
sired combination of options and enter the number found in the
Signal Value column.
Audio Signal (AUdio) Chart
Signal Value
Start Mode/
Remove Card
Serial or Net-
work Vend
Coin/Card
Vend or Start
Pulse End of Cycle Key Pressed
0 OFF OFF OFF OFF OFF
1 OFF OFF OFF OFF ON
2 OFF OFF OFF ON OFF
3 OFF OFF OFF ON ON
4 OFF OFF ON OFF OFF
5 OFF OFF ON OFF ON
6 OFF OFF ON ON OFF
7 OFF OFF ON ON ON
8 OFF ON OFF OFF OFF
Table 5 continues...
