Factory Test Cycle
To Enter Factory Test Cycle
1. Be certain control is in Ready Mode or Start Mode and access
panel or coin vault is open.
2. While pressing and holding the Ultra keypad with one hand,
press the Hot keypad with the other hand.
3. When the control enters Factory Test, it displays the first test
step, Machine Type.
4. The control advances through the sequence of test steps when
START (enter) is pressed, with the exception of the Keypad
Test and Pressure Sensor Test. Refer to Factory Test Quick
Reference Chart for all steps in the Factory Test.
To Exit Factory Test
To exit a test step, disconnect the machine from electrical power.
Factory Test Quick Reference Chart
Factory Test Cycles
Display Test Mode Comments
WX
Control Type
WX is the control type (Washer Extractor).
S XXX.XX
User Control Software Version Number
XXX is the software version number. .XX is
the software sub-version number.
ob XXX.XX
Input/Output Board Software Version
Number
XXX is the version number. .XX is the soft-
ware sub-version number.
AX
Control Level
X is the control level number.
XX
Dipswitch
XX is the value of the dipswitches in hexa-
decimal.
CH XXX
Machine Size
XXX is the machine capacity in pounds
drAin or PUNP
Drain Type Gravity drain or pump
dr oP or dr CL
Door Switch Test Door status open or closed.
dr UL or dr Lo
Door Lock Status The control locks the door and displays the
door status locked or unlocked. The user
cannot navigate to a previous step.
PAd XX
Keypad Test This step is used to verify keypad opera-
tion. XX is the keypad being pressed. Au-
to-advance to next step after all keypads
are pressed. The user cannot navigate to a
previous step.
8.8.8.8.8.8. + all LEDs
Display and Audio Test All display elements are lit and audio will
sound. The user cannot navigate to a previ-
ous step.
S oP or S CL
Service Door Switch Test Service door status open or closed. The
user cannot navigate to a previous step.
v oP or v CL
Coin Vault Switch Test Coin vault status open or closed.
CxCx
Coin Drop Test
1st x is number of Coin Drop #1 coins.
2nd x is number of Coin Drop #2 coins.
Table 36 continues...
Machine Diagnostic Functions
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
152 Part No. F8615401ENR4
