Factory Test Cycles
Display Test Mode Comments
CArd or LCSv or Sv
Card Reader Test
CArd is default. LCSv indicates card read-
er needs a programming/setup card. Sv
displays when programming/setup card is
successful. Test skipped if not equipped
with a card reader.
db XXX
Drive Board Software Version Number
XXX is the drive board software version
number.
PArXXX
Drive Parameter Version Number
XXX is the drive parameter version num-
ber.
XHPXXX
Drive Type Test
X is the horsepower rating. XXX is the rat-
ed drive voltage.
HottUb
Hot Tub Fill Hot tub fill valve is turned on and the ma-
chine fills to the high water level. Test
skipped if not equipped with valve.
CLdtUb
Cold Tub Fill Cold tub fill valve is turned on and the ma-
chine fills to the high water level. Test
skipped if not equipped with valve.
HotSPY
Hot Spray Fill Hot spray fill valve is turned on. Test skip-
ped if not equipped with valve.
CLdSPY
Cold Spray Fill Cold spray fill valve is turned on. Test
skipped if not equipped with valve.
Hot C1
Hot Fill through Compartment 1 The hot fill and compartment 1 valves are
turned on and the machine fills to the high
water level. If equipped, External Supply 1
is also turned on.
CLd C2
Cold Fill through Compartment 2 The cold fill and compartment 2 valves are
turned on and the machine fills to the high
water level. If equipped, External Supply 2
is also turned on.
WrN C3
Warm Fill through Compartment 3 The hot and cold fill and compartment 3
valves are turned on and the machine fills
to the high water level. If equipped, Exter-
nal Supply 3 is also turned on.
WrN C4
Warm Fill through Compartment 4 The hot and cold fill and compartment 4
valves are turned on and the machine fills
to the high water level. If equipped, Exter-
nal Supply 4 is also turned on.
CLdHrd
Cold Hard Fill Cold hard fill valve is turned on. Test skip-
ped if not equipped with valve.
AU vAL
Auxiliary Fill Auxiliary fill valve is turned on. Test skip-
ped if not equipped with valve.
Table 36 continues...
