Configuration Value
Dipswitch 8 (Drain)*
Dipswitch 7 (Electric Heat) **
Dipswitch 6 (Steam Heat)**
Dipswitch 5 (Unused)
Dipswitch 4 (Unused)
Dipswitch 3 (Payment System)**
Dipswitch 2 (Unused)
Dipswitch 1 (Volt Supply) ***
244 ON ON ON ON OFF ON OFF OFF
245 ON ON ON ON OFF ON OFF ON
246 ON ON ON ON OFF ON ON OFF
247 ON ON ON ON OFF ON ON ON
248 ON ON ON ON ON OFF OFF OFF
249 ON ON ON ON ON OFF OFF ON
250 ON ON ON ON ON OFF ON OFF
251 ON ON ON ON ON OFF ON ON
252 ON ON ON ON ON ON OFF OFF
253 ON ON ON ON ON ON OFF ON
254 ON ON ON ON ON ON ON OFF
255 ON ON ON ON ON ON ON ON
*OFF = Electric Pump, ON = Gravity Drain
**OFF = Not Present, ON = Present
***OFF = 120 VAC, ON = 240 VAC
Table 35
Machine Configuration #5 Display Test d 33
This option is not used on this model. 0 will always be displayed.
Low Level Pressure Switch Test (Heat Models) d
43
This test displays whether the Low Level Pressure Switch is open
or closed. To start test, control must be in the Testing Mode. Re-
fer to How to Enter Diagnostic Testing Feature at the beginning
of this section.
To enter, press the START (enter) keypad. If the door is open the
display will show show CLoSE, door until the the door is
closed. Once the door is closed the display will show LP oP if
the switch is open or LP CL if the switch is closed.
Machine Diagnostic Functions
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
151 Part No. F8615401ENR4
