Opening the Top Cover
To manually program the control, the top cover (located on the
top of the machine) must be unlocked and opened. Opening and
closing the top cover trips a switch which allows access to vari-
ous programming options. Once opened, it may be closed imme-
diately.
After opening and closing the top cover, the owner has 4 minutes
and 15 seconds to begin programming. If the appropriate keypads
have not been pressed in that time, the control will not accept
owner programming. Should this happen, opening and closing the
top cover will once again trip the switch which allows access to
the programming options.
1. Top Cover Lock
2. Top Cover
3. Top Cover Hinge
4. Peg
Figure 3
Opening the Top Cover
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
26 Part No. F8615401ENR4
