Configuration Value
Life Test Jumper Present
Comm Board "B" Header Present
Comm Board "A" Header Present
Vend Connection Present
Coin Drop #2 Present
Coin Drop #1 Present
61 YES YES YES YES NO YES
62 YES YES YES YES YES NO
63 YES YES YES YES YES YES
Table 32
Machine Configuration #2 Display Test d 30
This option shows the machine configuration values. To start test,
control must be in the Testing Mode. Refer to How to Enter Di-
agnostic Testing Feature at the beginning of this section.
To enter, press the START (enter) keypad. For configuration val-
ue #2, the display will show b XXX. XXX is a number corre-
sponding to the capacity size of the machine. Refer to Table 33 .
Option Description
1 20 Pound Cabinet Hardmount
2 30 Pound Cabinet Hardmount
3 40 Pound Cabinet Hardmount
4 60 Pound Cabinet Hardmount
5 80 Pound Cabinet Hardmount
6 100 Pound Cabinet Hardmount
Table 33
Machine Diagnostic Functions
©
