Configuration Value Life Test Jumper Present
Comm Board "B" Header Present
Comm Board "A" Header Present Vend Connection Present Coin Drop #2 Present Coin Drop #1 Present
36 YES NO NO YES NO NO
37 YES NO NO YES NO YES
38 YES NO NO YES YES NO
39 YES NO NO YES YES YES
40 YES NO YES NO NO NO
41 YES NO YES NO NO YES
42 YES NO YES NO YES NO
43 YES NO YES NO YES YES
44 YES NO YES YES NO NO
45 YES NO YES YES NO YES
46 YES NO YES YES YES NO
47 YES NO YES YES YES YES
48 YES YES NO NO NO NO
49 YES YES NO NO NO YES
50 YES YES NO NO YES NO
51 YES YES NO NO YES YES
52 YES YES NO YES NO NO
53 YES YES NO YES NO YES
54 YES YES NO YES YES NO
55 YES YES NO YES YES YES
56 YES YES YES NO NO NO
57 YES YES YES NO NO YES
58 YES YES YES NO YES NO
59 YES YES YES NO YES YES
60 YES YES YES YES NO NO
Table 32 continues...
Machine Diagnostic Functions
©
