Configuration Value Life Test Jumper Present
Comm Board "B" Header Present
Comm Board "A" Header Present Vend Connection Present Coin Drop #2 Present Coin Drop #1 Present
11 NO NO YES NO YES YES
12 NO NO YES YES NO NO
13 NO NO YES YES NO YES
14 NO NO YES YES YES NO
15 NO NO YES YES YES YES
16 NO YES NO NO NO NO
17 NO YES NO NO NO YES
18 NO YES NO NO YES NO
19 NO YES NO NO YES YES
20 NO YES NO YES NO NO
21 NO YES NO YES NO YES
22 NO YES NO YES YES NO
23 NO YES NO YES YES YES
24 NO YES YES NO NO NO
25 NO YES YES NO NO YES
26 NO YES YES NO YES NO
27 NO YES YES NO YES YES
28 NO YES YES YES NO NO
29 NO YES YES YES NO YES
30 NO YES YES YES YES NO
31 NO YES YES YES YES YES
32 YES NO NO NO NO NO
33 YES NO NO NO NO YES
34 YES NO NO NO YES NO
35 YES NO NO NO YES YES
Table 32 continues...
Machine Diagnostic Functions
©
