Factory Test Cycles
Display Test Mode Comments
ALL Hi
All Fill to High Level All equipped valves are turned on. The test
will advance when the high water level is
reached.
t XXXF or t XXXC
Thermistor/Temperature Sensor Test
XXX is the temperature of the water in
Fahrenheit or Celsius. This test skipped if
not configured with a thermistor or a heat-
er.
E XXXF or E XXXC
Electric Heater Test
XXX is the temperature of the water in
Fahrenheit or Celsius. The electric heater
turns on until the water temperature reach-
es 104°F [40°C] , at which point the elec-
tric heater turns off. The electric heater
will turn back on if the water temperature
drops below that level 104°F [40°C] . This
test skipped if not configured with a heat-
er.
S XXXF or S XXXC
Steam Heater Test
XXX is the temperature of the water in
Fahrenheit or Celsius. The electric heater
turns on until the water temperature reach-
es 104°F [40°C] , at which point the elec-
tric heater turns off. The electric heater
will turn back on if the water temperature
drops below that level 104°F [40°C] . This
test skipped if not configured with a heat-
er.
LoAgXX
Low Agitate Test The basket rotates forward and reverse at
low agitate speed. The right most decimal
point is lit when rotation is in the negative
direction. The user cannot navigate to a
previous step.
rEAgXX
Regular Agitate Test The basket rotates forward and reverse at
regular agitate speed. The Right most deci-
mal point is lit when rotation is in the neg-
ative direction. The user cannot navigate to
a previous step.
drAin or PUNP
Drain Test The machine will drain. Once the machine
is empty the test can be advanced. The
user cannot navigate to a previous step.
PUrge
Purge Test The basket rotates at distribution speed
and all equipped valves are turned on so
compressed air can be used to purge the
valves of water. The user cannot navigate
to a previous step.
Table 36 continues...
