Factory Test Cycles
Display Test Mode Comments
baL XX
Balance Test The basket rotates at distribute speed.
While the balance procedure is being exe-
cuted the display will show two dipping
dashes (--) where the XX is. Once the bal-
ance procedure is complete the allowed
speed will be displayed:vl (very low)/ L
(low)/ M (medium)/ H (high)/ vH (very
high)/ UH (ultra high). Once the machine
has finished balancing the test can be ad-
vanced. Press the Warm (<) keypad to re-
start the test. The user cannot navigate to a
previous step.
vLoXXX
Very Low Speed Spin Test
XXX will show the RPM of the basket. The
test can be advanced at any time or will
automatically advance after 2 minutes.
This test is skipped if the load did not bal-
ance for the speed or the machine is model
does not allow this speed.
Lo XXX
Low Speed Spin Test
XXX will show the RPM of the basket. The
test can be advanced at any time or will
automatically advance after 2 minutes.
This test is skipped if the load did not bal-
ance for the speed or the machine is model
does not allow this speed.
NEdXXX
Medium Speed Spin Test
XXX will show the RPM of the basket. The
test can be advanced at any time or will
automatically advance after 2 minutes.
This test is skipped if the load did not bal-
ance for the speed or the machine is model
does not allow this speed.
Hi XXX
High Speed Spin Test
XXX will show the RPM of the basket. The
test can be advanced at any time or will
automatically advance after 2 minutes.
This test is skipped if the load did not bal-
ance for the speed or the machine is model
does not allow this speed.
vHiXXX
Very High Speed Spin Test
XXX will show the RPM of the basket. The
test can be advanced at any time or will
automatically advance after 2 minutes.
This test is skipped if the load did not bal-
ance for the speed or the machine is model
does not allow this speed.
Table 36 continues...
Machine Diagnostic Functions
©
