Display Description Cause/Corrective Action
Eio 62
24 Volt Supply Over Voltage The control sounds an alarm tone for 15 seconds.
To clear this error either power down the machine or simultaneous-
ly press the Normal and Warm keypads.
Eio 63
24 Volt Supply Under Voltage The control sounds an alarm tone for 15 seconds.
To clear this error either power down the machine or simultaneous-
ly press the Normal and Warm keypads.
E dr
Drain Error If enabled, the control will enter Machine Error Mode when the
water height is not below the empty level, after attempting to drain
for the programmable time (default 15 minutes).
The control sounds an alarm tone for 15 seconds.
To clear the error, disconnect and then reconnect power to the ma-
chine.
E LF
Water Leak Fill Error If the water level has raised more than an acceptable amount in a
during a water leak check, the control will save a water leak error
status and will continue the machine cycle. Immediately upon de-
tecting the error the right-most decimal point will be lit. This lit dec-
imal point can be cleared by pressing the START (enter) keypad 3
times in a period of 5 seconds or by cycling the power to the ma-
chine.
E d 01
Setup Command Error Drive received incorrect parameters. Power down machine to clear.
Call a service technician if error persists.
E d 21
Over Voltage DC Bus Error Power down to clear error. Check voltage input to machine. If it
happens only at start of spin, replace motor. Replace drive board if
error persists.
E d 22
Over Motor Temperature Error Motor temperature is detected to be too high. Check that drum spins
freely when empty. Check for overloading of machine. Check motor
harness for damage. Reduce agitation time and duty cycle if rotate/
pause times are very short and programmable. Power down to clear
error. Replace drive board if error persists.
E d 23
Fatal IPM Over Current Shunt Error Check that drum and motor spins freely. Power down to clear error.
Check the motor phase windings. Continuity should be uniform be-
tween phases L1 and L2, L2 and L3, L1 and L3. Replace motor if
not uniform. Replace drive board if error persists.
E d 24
Fatal I2T Hardware Over Current
Error
Check that drum and motor spins freely. Rotor may be locked up.
Check the motor phase windings. Continuity should be uniform be-
tween phases L1 and L2, L2 and L3, L1 and L3. Replace motor if
not uniform. Power down to clear error. Replace drive board if error
persists.
E d 25
IPM Over Temperature Error IPM temperature is detected to be too high. Check that drum spins
freely when empty, check for overloading of machine, reduce agita-
tion time, and duty cycle if rotate/pause times are very short and
programmable. Power down to clear error. Check for lint build-up
on heat sink on drive board. Replace drive board if error persists.
Table 37 continues...
