Programming the Soak Step Type
The Soak Step Type allows the owner to program a soak step in a
cycle. The Soak Step Type is identical to the Agitate Step Type
except that it allows hours and minutes to be programmed rather
than minutes and seconds. After selecting the desired Cycle Step
number and pressing START (enter), XXSoAk will appear in the
display. Press the Delicates Bulky (∧) or the Cold (∨) keypad to
scroll through the options and START (enter) to select a value.
NOTE: To go back to the current programmable option
without changing the value of the active digit, press the
Warm (<) keypad.
Step
Type
Display
A Display B Values Description
XXSoAk Soak Step Type (XX is step number, step type is flash-
ing)
En diS XXSo01 EnAbLe/diSAbL/dNod 1/
dNod 2
Step Enable/Disable
Choosing dNod 1 and dNod 2 will enable the step
if the cycle modifier is chosen and set to be enabled
in Cycle Modifier Programming Menu CNP-.
StAtUS XXSo02 PrEWSH/WASH/rinSE1/
rinSE2/rinSE3/rinSE4/
SPin
Status LED: The corresponding LED on the control
will be lit during this step.
HoUrS XXSo03
0-255 Step Hours: If Programmed Cycle Time Display is en-
abled and set to a value greater than zero, it will over-
ride this time.
NinUtE XXSo04
0-59 Step Minutes: If Programmed Cycle Time Display is
enabled and set to a value greater than zero, it will
override this time.
HEAt XXSo05 no/tArgEt/MAintA
Heater Temperature (refer to Heating/Cool Down Dis-
play Sequence (Heat Models))
rAtE XXSo06 no/
Heat Rate
rotAtE XXSo07
3-255 Motor On Time (seconds)
PAUSE XXSo08
3-255 Motor Off Time (seconds)
SPEEd XXSo09 no rot/LoW Ag/rEg Ag/
10-50 RPM (X.XX-X.XX G
Force)
Rotation Speed: no rotation, low agitate speed, regu-
lar agitate speed or custom speed in RPM/G Force
• 0.03-0.75 for 20 pound
• 0.04-0.86 for 30 pound
• 0.04-0.94 for 40 pound
• 0.05-1.07 for 60 pound
• 0.06-1.27 for 80 pound
• 0.06-1.27 for 100 pound
rEvErS XXSo10 rEv on/no rEv
Reversing
drAin1 XXSo11 on/oFF
Drain #1
drAin2 XXSo12 on/oFF
Drain #2
Table 20 continues...
