Chapter 5: IP Core Interfaces 5–9
Avalon-ST TX Interface
November 2011 Altera Corporation Cyclone V Hard IP for PCI Express
User Guide
tx_st_ready
(1)
1O ready
Indicates that the Transaction Layer is ready to accept data
for transmission. The core deasserts this signal to throttle
the data stream.
tx_st_ready may be asserted during
reset. The Application Layer should wait at least 2 clock
cycles after the reset is released before issuing packets on
the Avalon-ST TX interface. The
reset_status signal can
also be used to monitor when the Hard IP has come out of
reset.
If
tx_st_ready is asserted by the Transaction Layer on
cycle <n>, then <n +
readyLatency > is a ready cycle,
during which the Application Layer may assert
valid and
transfer data.
When
tx_st_ready , tx_st_valid and tx_st_data are
registered (the typical case), Altera recommends a
readyLatency
of 2 cycles to facilitate timing closure;
however, a
readyLatency of 1 cycle is possible.
tx_st_valid
(1)
1I valid
Clocks tx_st_data to the Hard IP when tx_st_ready is
also asserted. Between
tx_st_sop and tx_st_eop ,
tx_st_valid can be asserted only if tx_st_ready is
asserted. When
tx_st_ready deasserts, this signal must
deassert within 1 or 2 clock cycles. When
tx_st_ready
reasserts, and
tx_st_data is in mid-TLP, this signal must
reassert within 2 cycles. Refer to Figure 5–12 on
page 5–13 for the timing of this signal.
To facilitate timing closure, Altera recommends that you
register both the
tx_st_ready and tx_st_valid signals.
If no other delays are added to the ready-valid latency, the
resulting delay corresponds to a
readyLatency of 2.
tx_st_err 1I error
Indicates an error on transmitted TLP. This signal is used to
nullify a packet. It should only be applied to posted and
completion TLPs with payload. To nullify a packet, assert
this signal for 1 cycle after the SOP and before the EOP.
When a packet is nullified, the following packet should not
be transmitted until the next clock cycle.
tx_st_err is not
available for packets that are 1 or 2 cycles long. The error
signal must be asserted while the valid signal is asserted.
Component Specific Signals
tx_cred_datafccp 12 O
component
specific
Data credit limit for the received FC completions. Each
credit is 16 bytes.
tx_cred_datafcnp 12 O
component
specific
Data credit limit for the non-posted requests. Each credit is
16 bytes.
tx_cred_datafcp 12 O
component
specific
Data credit limit for the FC posted writes. Each credit is 16
bytes.
Table 5–4. 64- or 128-Bit Avalon-ST TX Datapath (Part 2 of 3)
Signal Width Dir
Avalon-ST
Type
Description
