6. Redundancy with NX3030 CPU
339
Table 6-8. NETB Interface Specific Diagnostics
The “sNET_Stat” substructure has service success and failure statistics. The local and remote PLCs
statistics can be restarted through commands:
//Local PLC
DG_NX4010.tRedundancy.RedCmdLoc.bResetNETStatisticsLocal := TRUE;
//Remote PLC
DG_NX4010.tRedundancy.RedCmdLoc.bResetNETStatisticsRemote := TRUE;
The substructure has the following counters:
Direct
Representation
Variable
AT Variable
DG_NX4010.tRedundancy.
RedDgnLoc.sNET_Stat.*
Description
%QW(n+35)
wSuccessExchDgCmdSync
Success counting of the Diagnostics and
Commands service (0 to 65535)
%QW(n+37)
wFailedExchDgCmdSync
Failure counting of the Diagnostics and
Commands service (0 to 65535)
%QW(n+39)
wSuccessRedDataSync
Success counting of the Redundant Data
Synchronization service (0 to 65535)
%QW(n+41)
wFailedRedDataSync
Failure counting of the Redundant Data
Synchronization service (0 to 65535)
%QW(n+43)
wSuccessRedForceSync
Success counting of the Redundant Forcing List
Synchronization service (0 to 65535)
%QW(n+45)
wFailedRedForceSync
Failure counting of the Redundant Forcing List
Synchronization service (0 to 65535)
Table 6-9. Interface Specific Diagnostics
Note:
Counters: All counters return to zero when its limit value is exceeded.
The sub structure “sGeneral_Diag” owns the following fields to general redundancy diagnostics:
Direct Representation
Variable
Variável AT
DG_NX4010.tRedundancy.RedDgn
Loc.sGeneral_DiagExt.*
Description
Variable
Bit
%QB(n+47)
0
bFailedPBUS3A
TRUE – This PLC can’t communicate in
the master state (active or passive) in the
PROFIBUS 3 A network. The master mode
(communicating with slaves) is assumed
by the Active PLC. The passive mode
(communicating with the active master) is
assumed by the Non-Active PLC. This
failure can also be indicated in case the
NX5001 module has a microprocessor
failure, or in case it can’t communicate with
the NX3030 CPU via bus.
FALSE – There aren’t failures in the
PROFIBUS 3 A network.
1
bFailedPBUS3B
TRUE – This PLC can’t communicate in
the master state (active or passive) in the
PROFIBUS 3 B network. The master mode
(communicating with slaves) is assumed
by the Active PLC. The passive mode
(communicating with the active master) is
assumed by the Non-Active PLC. This
failure can also be indicated in case the
NX5001 module has a microprocessor
failure, or in case it can’t communicate with
the NX3030 CPU via.
FALSE – There aren’t failures in the
PROFIBUS 3 B network.
