9. Annex A. DNP3 Interoperability
DNP3 Device Profile
DNP3
DEVICE PROFILE DOCUMENT
Device Identification
Vendor Name
Altus S/A
Device Name
NX3030
Device Function
Slave
DNP Levels Supported for
Requests: None
Responses: None
Connections Supported
IP Networking
Methods to set Configurable Parameters
Software: Master Tool IEC XE
IP Networking
Type of End Point:
TCP Listening (Outstation Only)
Accepts TCP Connections from
Allows all
IP Address(es) from which TCP Connections are
accepted:
*.*.*.*
TCP Listen Port Number
Configurable, range 1to 65535
TCP Keep-alive timer
Configurable, range 0 to 4294967295
Multiple master connections
Supports up to two masters
Based on TCP port number
Time synchronization support
SNTP
Link Layer
Data Link Address
Configurable, range 0 to 65519
Self Address Support using address 0xFFFC
No
Requires Data Link Layer Confirmation
Never
Maximum number of octets Transmitted in a Data
Link Frame
Fixed at 292
Maximum number of octets that can be Received
in a Data Link Frame
Fixed at 292
Application Layer
Maximum number of octets Transmitted in an
Application Layer Fragment
Fixed at 2048
Maximum number of octets that can be received in
an Application Layer Fragment
Fixed at 2048
Timeout waiting for Application Confirm of solicited
response message
Fixed at 10000 ms
Device Trouble Bit IIN1.6
This bit will be set if PLC is not in Run mode
Event Buffer Overflow Behavior
Discard the oldest event
Sends Multi-Fragment Responses
Yes
Outstation Unsolicited Response Support
Supports Unsolicited Reporting
No
