2. Technical Description
12
information. This area is shared with source code memory, being the total area the sum of “program
memory” and “source code memory”.
User files memory: This memory area offers another way for the user to store files such as doc, pdf,
images, and other files. This function allows data recording as in a memory card. For further
information check User Files MemoryUser Files Memory.
Maximum number of tasks: The maximum number of tasks defined for each CPU model, and
among different project profiles, is better detailed in the chapter Maximum Number of Tasks.
Redundancy support (half-clusters): The software version 1.1.0.0 or onwards/product revision AB
or onwards supports redundancy of NX3030 CPUs.
Event oriented data reporting (SOE): The data types are found in the DNP3 Device Profile.
Maximum number of PROFIBUS-DP network: From MasterTool IEC XE version 1.22 and
onwards, 4 PROFIBUS-DP networks are supported for NX3020 and NX3030 CPUs. Previous
versions support 2 PROFIBUS-DP networks. The limit of PROFIBUS-DP masters is 4, which means
that only 2 redundant networks can be used.
Serial Interfaces
COM 1(NX3010/NX3020/NX3030)
NX3010, NX3020, NX3030
Connector
Shielded female DB9
Physical interface
RS-232C
Modem signals
RTS, CTS, DCD
Baud rate
200, 300, 600, 1200, 1800, 2400, 4800, 9600, 19200, 38400,
57600, 115200 bps
Protocols
Master/ Slave MODBUS RTU
Open protocol
Table 2-8. COM 1 Serial Interface Features
COM 1 (NX3004/NX3005) and COM 2 (NX3010/NX3020/NX3030)
NX3004, NX3005, NX3010, NX3020, NX3030
Connector
Shielded female DB9
Physical interface
RS-422 or RS-485 (depends on the cable choice)
Communication direction
RS-422: full duplex
RS-485: half duplex
RS-422 maximum transceivers
11 (1 transmitter and 10 receivers)
RS-485 maximum transceivers
32
Termination
Yes (optional via cable selection)
Baud rate
200, 300, 600, 1200, 1800, 2400, 4800, 9600, 19200, 38400,
57600, 115200
Protocols
Master/ Slave MODBUS RTU
Open protocol
Table 2-9. COM 2 Serial Interface Features
Notes:
Physical Interface: Depending on configuration of the used cable it is possible to choose the kind of
physical interface: RS-422C or RS-485. The list of cables can be found at Related Products section.
RS-422 Maximum Transceivers: It is the maximum number of transceivers that can be used on a
same bus.
