4. Configuration
187
ATTENTION:
If the memory card is removed without have been unmounted through CPU’s menu, during a file
transference, this process can cause the lose of card data as well as corrupt the files in it. This
process may cause the need of another card formatting when it'll be inserted on the CPU again.
ATTENTION:
If there is any file at memory card root named “NextoMemCard” or “Backup”, it will be deleted to
create the system folders with the same name, used by the CPU to store the project application and
the project archive. Folders with these names will not be overwritten.
MasterTool Access
The memory card access is connected to the same user memory screen in the MasterTool IEC XE
software, being it mounted in the folder called “Memory Card”. “NextoMemCard” and “Backup"
folders are created into the memory card every time the latter is inserted into the CPU. In case these
folders already exist, the system will recognize them and will not overwrite the folders.
Figure 4-90. Root Directory with Memory Card Inserted
The file transference happens in a similar way to the user memory utilization (User Files Memory).
Access the folder “MemoryCard” and send the files as depicted on Figure 4-91.
