7. Maintenance
362
%QD(n+179)
DWORD
Ethernet.NET1.
dwPacketsSent
Counter of sent packages through
NET 1 port. (0 to 4294967295)
%QD(n+183)
DWORD
Ethernet.NET1.
dwPacketsReceived
Counter of received packages
through NET 1 port. (0 to
4294967295)
%QD(n+187)
DWORD
Ethernet.NET1.
dwBytesSent
Counter of sent bytes through
NET 1 port. (0 to 4294967295)
%QD(n+191)
DWORD
Ethernet.NET1.
dwBytesReceived
Counter of received bytes through
NET 1 port. (0 to 4294967295)
%QW(n+195)
WORD
Ethernet.NET1.
wTXErrors
Counter of errors of transmission
through NET 1 port. (0 to 65535)
%QW(n+197)
WORD
Ethernet.NET1.
wTXFIFOErrors
Counter of errors in the buffer of
transmission through NET 1 port.
(0 to 65535)
%QW(n+199)
WORD
Ethernet.NET1.
wTXDropErrors
Counter of connection losses in
the transmission through NET 1
port. (0 to 65535)
%QW(n+201)
WORD
Ethernet.NET1.
wTXCollisionErrors
Counter of errors of collision in the
transmission through NET 1 port .
(0 to 65535)
%QW(n+203)
WORD
Ethernet.NET1.
wTXCarrierErrors
Counter of errors of the carrier in
the transmission through NET 1
port. (0 to 65535)
%QW(n+205)
WORD
Ethernet.NET1.
wRXErrors
Counter of errors of reception
through NET 1 port. (0 to 65535)
%QW(n+207)
WORD
Ethernet.NET1.
wRXFIFOErrors
Counter of errors in the buffer of
reception through NET 1 port. (0
to 65535)
%QW(n+209)
WORD
Ethernet.NET1.
wRXDropErrors
Counter of connection losses in
the reception through NET 1 port.
(0 to 65535)
%QW(n+211)
WORD
Ethernet.NET1.
wRXFrameErrors
Counter of errors of frame in the
reception through NET 1 port. (0
to 65535)
%QW(n+213)
WORD
Ethernet.NET1.
wMulticast
Counter of multicast packages
through NET 1. (0 to 65535)
%QW(n+215)
WORD
Ethernet.NET1.
wReserved_0
Reserved
%QW(n+217)
WORD
Ethernet.NET1.
wReserved_1
Reserved
Table 7-17. Ethernet NET 1 Detailed Diagnostics Group Description
CPU Direct Representation Variable
Size
DG_Modulo.tDetailed.*
AT Variable
Description
NX3004
NX3005
NX3010
NX3020
NX3030
NA
%QX(n+219).0
BIT
Ethernet.NET2.
bLinkDown
Indicates the link state in NET 2.
NA
%QW(n+220)
WORD
Ethernet.NET2
.wProtocol
Protocol selected in NET 2:
00: Without protocol
NA
%QX(n+220).0
BIT
Ethernet.NET2.
wProtocol.bMODBUS_R
TU_ETH_Client
MODBUS RTU Client via TCP
NA
%QX(n+220).1
BIT
Ethernet.NET2.
wProtocol.bMODBUS_E
TH_Client
MODBUS TCP Client
NA
%QX(n+220).2
BIT
Ethernet.NET2.
wProtocol.bMODBUS_R
TU_ETH_Server
MODBUS RTU Server via TCP
NA
%QX(n+220).3
BIT
Ethernet.NET2.
wProtocol.bMODBUS_E
TH_Server
MODBUS TCP Server
NA
%QB(n+222)
STRING
(15)
Ethernet.NET2.
szIP
IP NET 2 Address
NA
%QB(n+238)
STRING
Ethernet.NET2.
NET 2 Subnet Mask
