LW500A/LW600A PULSED Nd:YAG LASER
990-539 A-1
APPENDIX A
Technical Specifications
Section I. Specifications
LW500A/600A SPECIFICATIONS (220VAC Models)
Oscillator
Parameter
LW500A / ML-2651B LW600A ML-2650B
Maximum Rated Output 500W 600W
Maximum Output
Energy
80J/P (at 10ms) 100J/P (at 10ms)
Pulse Width
Standard: 0.3 – 99.9mS (0.1mS increment)
Fine Setting: 0.25 – 5.00mS (0.05mS increment)
Pulse Repetition Speed 1 to 500 pps
Oscillator Wavelength
1.064 m
Resonator Shutter With open/close sensor
Positioning Guide
Beam
Built-in visible laser (Red)
Output stability
± 3 % (with output pulse
 5J/pulse and peak power  1 kW)
Power Supply
Power Supply
220 VAC + 10%/-15%, 3-phase, 50/60Hz
(Jumper selectable for 200/240 VAC. Consult with Amada Miyachi America)
Max. Input Current 84A (at 220VAC)
Max. apparent power
31.1 kVA (at 220VAC)
Breaker rated current
100A
Power Consumption
25.4kW Maximum (2.3kW Stand-by)
Cooler
Heat Exchanger Method Water-Water
Pressure(maximum)
Water Temperature
Flow Rate
Differential Pressure
42.6 psi (or 294 kPa)
5 - 35C (41 - 95F)
25 liters/min at 25°C/77F
55 liters/min at 32°C/90F
14.2  42.6 psi (98  294 kPa)
Chiller requirements 6.68 Ton (80,185 BTU/h, 20,160 kcal/h)
Inner diameter of hose
19 mm
Laser
Controller
Schedule Setting Up to 32 schedules
Monitor
Energy Monitor (J)
Average Power (W)
Counter
9-digit TOTAL counter
9-digit GOOD counter
Alarm indication Messages are displayed on liquid crystal display
Length of Cable Remote control through standard 3m cable (9.8 ft.)
Physical
Properties
Mass (approximately) Approximately 1,190 lbs. (540 kg)
Outline dimensions
47.2" (H) x 19.7" (W) x 70.1" (D)
1200 mm (H) x 500 mm (W) x 1780 mm (D)
