CHAPTER 5: MAINTENANCE
LW500A/LW600A PULSED Nd:YAG LASER
5-24 990-539
Section V: Parts Lists
Accessories
Name
Amada Miyachi America
Part Number
EXT. I/O (1) connector (37 pin male) 250-409
37 pin D-sub Backshell 250-537
EXT. I/O (2) connector (25 pin male) 250-479
EXT. I/O (4) connector (25 pin female) 250-480
25 pin D-sub Backshell 250-536
EXT. I/O (3) E-STOP connector (9 pin male) 250-193
9 pin D-sub Backshell 250-535
RS-485 connector (1) or (2) 451-052
REMOTE INTERLOCK connector 451-035
Fiber interlock connector 520-139
Ion-exchange resin replacing tool 451-082
Nd:YAG laser-protective glasses 475-118
Ball point hex screwdriver 2.5mm 770-035
Ball point hex screwdriver 3mm 770-036
Ball point hex screwdriver 4mm 770-037
Water feed hand pump PH-10
Operation manual 990-539
Fiber Scope FOS-04
Consumable Parts
Name
Amada Miyachi America
Part Number
Flashlamp (MLD-0861), LW500A/600A 435-138 (x2)
Flow tube, Flashlamp, LW500A/600A Z-01981-003
Flow tube, Nd:YAG rod, LW500A/600A Z-02390-001
Ion-exchange resin refill 318-026
Ion-exchange cartridge 318-025
Ion-exchange resin cartridge kit
(With one bag of ion-exchange resin)
318-027
Cooling water (Distilled water) 900-241
Water filter 4-60081-01
Floating Panel Z-02362-001
Lithium battery 145-014
Rear Fan Filter (265mm x 250mm x 20mm) HR1320TX265X250 (x2)
Rear Fan Filter (170mm x 270mm x 15mm) 451-136
Rear Fan Filter (120mm x 120mm) FL12
