CHAPTER 3: PROGRAMMING FUNCTIONS
LW500A/LW600A PULSED Nd:YAG LASER
990-539 3-25
SW3
Position Function ON OFF (default)
SW3-1 Not Used
SW3-2
Laser Start/Accept Times (See table below)
SW3-3
SW3-4
SW3-5 Not Used
SW3-6
Trigger Signal Enable
(firmware ≥ V00-02H)
Trigger Signal Output on
EXT-I/O(1) – Pin 7
No Trigger Output
SW3-7 Not Used
SW3-8 Not Used
Laser Accept Times SW3-4 SW3-3 SW3-2
16ms (default) OFF OFF OFF
8ms OFF OFF ON
4ms OFF ON OFF
1ms OFF ON ON
0.1ms ON
X X
SW4 (see APPENDIX B, Section III for more information on Independent Control)
Position Function
SW4-1
Branch Shutter 1 – When in Independent Control mode, turn ON if branch shutter is installed.
SW4-2
Branch Shutter 2 – When in Independent Control mode, turn ON if branch shutter is installed.
SW4-3
Branch Shutter 3 – When in Independent Control mode, turn ON if branch shutter is installed.
SW4-4
Branch Shutter 4 – When in Independent Control mode, turn ON if branch shutter is installed.
SW4-5 to SW4-8 Not Used
SW5 (see APPENDIX B, Section III for more information on Independent Control)
Position Function
SW5-1
Time-Share 1 – When in Independent Control mode, turn ON if time-share shutter is installed.
SW5-2
Time-Share 2 – When in Independent Control mode, turn ON if time-share shutter is installed.
SW5-3
Time-Share 3 – When in Independent Control mode, turn ON if time-share shutter is installed.
SW5-4 to SW5-8 Not Used
SW6 - Not Used
