Putting to operation
Cirrus 3/4/6000 DB2034 08.04
105
- Actuate control unit 1 until the machine wings have
fully been folded in.
Fig. 165
The locking hooks (Fig. 166/1) act as a mechanical
transport locking and catch on the locking journals (Fig.
166/2).
Danger!
Ensure that the latches (Fig. 166/1)
have caught properly after having
folded in the wings.
Fig. 166
- Actuate control unit 2 to lower the machine into the
transport position.
Important
Lower the machine only to that extent
that the machine has sufficient ground
clearance in all situations of travel.
Danger!
Switch off
Danger!
The transport of the machine with filled
seed hopper on public roads and ways
is prohibited. The braking system is
only designed for the empty machine.
Fig. 167
