Description of product
32
Cirrus 3/4/6000 DB2034 08.04
Fig. 32/...
1
Hydro reservoir with nitrogen filling to pre-
tension the folded out machine wings
Fig. 32
3.2 Danger zones
Danger zones exist
• between tractor and implement, particularly when hitching on or off or when filling
the seed tank
• within the operational range of moving parts
• when climbing on to the machine
• in the swivel range of the track markers
• in the swivel range of the machine wings
• underneath lifted, not secured machines or machine parts
• when folding in and out the machine wings within the range of high voltage lines
by touching them.
Within these zones permanently existing danger or unexpectedly arising danger exist.
Safety symbols identify these danger zones. In this case, particular safety advices are
valid (please also refer to chapter 2.16, page 17).
