Malfunction
118
Cirrus 3/4/6000 DB2034 08.04
8. Malfunction
8.1 Indication of low seed hopper contents
When the seed level falls below the residual amount
(with properly adjusted seed level sensor) a waning
alarm (Fig. 191) appears in the with
an audible signal.
The residual amount should be sufficiently large to
avoid deviations in the application rate or now sown
areas.
Fig. 191
8.2 Fault in the metering system
If the metering wheel is blocked due to foreign
particles in the metering unit, a plastic bolt (Fig. 192/1)
shears off and the drive is stopped to avoid any
damage.
Fig. 192
When a metering wheel is stopped a warning alarm
(Fig. 193) appears in the display of
and an audible alarm sounds.
Fig. 193
