Settings
Cirrus 3/4/6000 DB2034 08.04
85
- Slacken bolts (Fig. 130/1).
- Adjust the marker discs in such a way that they
mark the tramline which has been created by the
tramline coulters.
- Turn the discs (on light soils the discs should be
placed about parallel seen in driving direction and
more on grip on heavy soils) to adapt the working
intensity to the prevailing soil contour.
- Firmly retighten bolts (Fig. 130/1).
Fig. 130
Hint!
When operating with tramline rhythm 2 and tramline rhythm 6plus (also see
chapter 5.10.1.3) only fit one of the two marker discs.
The wheel track of the husbandry tractor is marked during one travel to and fro
in the field.
5.12 Setting the running time of the pre-charging system on the headlands
Setting the running time of the pre-charging system on
the headlands :
- Open page 3 (Fig. 131) in the menu basic data.
- Input of running time (seconds) for the pre-
charger.
Fig. 131
