Assembly and function
54
Cirrus 3/4/6000 DB2034 08.04
4.17 Braking system
Cirrus is equipped with an air braking system with hydraulically actuated brake cylinder
for the brake shoes in the brake drum.
Important
Cirrus is not provided with a parking brake.
Always secure the machine against rolling away with chocks before coupling the
machine off the tractor.
4.18 Electric hydraulic control block
All hydraulic functions of the machine are actuated via
the electric hydraulic control block.
Initially select the desired hydraulic function in
and carry out the hydraulic function
via the related control valve.
The release of the hydraulic functions in
allows the actuation of all hydraulic
functions with just 3 control valves.
Fig. 77
