Settings
82
Cirrus 3/4/6000 DB2034 08.04
5.10.2 Setting the tramline rhythm
Input of tramline rhythm in :
- Select the tramline rhythm from table (Fig. 119).
- Open page 1 (Fig. 123) in the menu machine data.
- Input of the desired tramline rhythm.
Enter the selected tramline rhythm into
.
Fig. 123
5.10.3 Setting the tramline counter
At the beginning of the first run in the field enter the
tramline counter of the first run in the field in the
terminal.
Take the tramline counter of the first run in the field
from the illustration (Fig. 120).
For setting the tramline counter
Open the menu operation (Fig. 124) in
Press the key or until the required
tramline counter (Fig. 124/1) is shown.
Fig. 124
Hint!
The tramline counter is coupled with the operation sensor on the star wheel.
Every time the machine is lifted, the tramline counter advances by one digit.
In case it is intended to prevent the shifting on of the tramline counter when the
machine is lifted,
first press the STOP-key ,
then lift the machine.
The function of the STOP key is activated when the symbol (Fig. 124/2) appears
in the operation menu.
Prior to lower the folded machine
lock the star wheel (see chapter 7.7), to prevent the unintended lowering of the
star wheel and the undesired shifting on of the tramline counter.
