Description of product
36
Cirrus 3/4/6000 DB2034 08.04
3.5 Technical data
Cirrus 3000 Cirrus 4000 Cirrus 6000
see Figure
(Fig. 42)
see Figure
(Fig. 43)
see Figure
(Fig. 44)
Working width
[m] 3,0 4,0 6,0
Number of packer coulters
24 32 48
Row spacing of coulters
[cm] 12,5
Area output
[ha/h] ca. 2,2 ca. 3,0 ca. 4,8
Capacity seed tank
[l] 2200 2200 3000
Soil cultivation
trailed with disc cultivator
Operational speed
[km/h] 12 to 16
Total length
[m] 7,92
Brakes-interface
tractor joint
air braking system
effective brake system
in the integrated transport device
hydraulic brake system
Transport wheels
4x400/50-15,5
Required
tractor hydraulic capacity
min. 80 l/min, at max. 200 bar
Drawbar coupling
lower link cat. III
Gearbox, hydraulic oil,
Tip: suitable for the combined
hydraulic-/gearbox oil circuits of all
common tractor makes.
Gearbox-/Hydraulic oil Utto SAE 80W API GL4
Electric tractor joint
12 Volt/7-pin socket
Permissible max. speed
on all not public and public roads and
ways
(only with an empty seed box)
[km/h] 40
Basic weight
[kg] 4530 6080 7880
Permissible total weight
[kg] 4700 6300 8000
Max. load for road transport
[kg] 170 220 120
Permissible rear axle load
[kg] 4000 5300 6650
Permissible front support load
[kg] 1200 1500 1230
Transport width
(from 4 m working width, folded)
[m] 3,0
Total height in transport position
(from 4 m working width, folded)
[mm] 2700 2700 3500
