Settings
78
Cirrus 3/4/6000 DB2034 08.04
5.10.1.1 Example for creating tramlines
Some examples for the creation of tramlines are illustrated r (Fig. 120):
A = Working width of the seed drill
B = Tramline distance (= working width fertiliser spreader/field sprayer)
C = Tramline rhythm (Input into )
D = Tramline counter (during operation, the tramline travels are numbered all the
way through and displayed in ).
Carry out inputs and indications following the operator's manual for .
Example:
Working width seed drill: 6 m
Working width fertiliser spreader / field sprayer: 18 m = 18 m tramline distance
1. In the opposite table (Fig. 120) find:
in column A the working width of the seed drill (6 m) and
in column B the tramline distance (18 m).
2. In the same line in column "C" find the tramline rhythm (tramline rhythm 3) and set in
.
3. In the same line in column "D" below the word "START" find the tramline counter for
the first field travel (tramline counter 2) and set in . Enter this value
only immediately before the first travel in the field.
