Introduction User manual
Total station model Remarks
Leica TPS1200
Leica TS15/16
Leica TS30
Leica TS50/60
Leica MS50/60
■
Total station must be equipped with
the feature Automatic Target Recognition
(ATR) and must support the lock to the
prism for kinematic survey.
■
A red-laser (used for reflectorless
measurement RL) is highly recommended.
■
Please ensure you have the robotics
license (Geocom) for total station models
TPS1200, TS15/16, TS30, TS50/60 and
MS50/60.
1.5.2 GNSS system for georeferencing of GRP System FX
The following GNSS systems are supported for the operation together with the GRP System
FX:
GNSS model Remarks
Leica GNSS1200
Leica GS10/14/15/16/18
■
The mentioned systems require different
cable sets to connect to the GRP System
FX.
1.5.3 High-speed laser scanner for the configuration GRP/IMS 5000
The following high-speed laser scanners are supported for the operation together with the GRP
System FX:
High-speed laser scanner model Remarks
Amberg Profiler 5002 (2D laser scanner)
Amberg Profiler 5003 (3D laser scanner)
Amberg Profiler 5033 (3D laser scanner)
Amberg Profiler 6012 (2D laser scanner)
Z+F Profiler 5006 (2D laser scanner)
Z+F Imager 5006h (3D laser scanner)
Z+F Imager 5010 (3D laser scanner)
Z+F Profiler 9012 (2D laser scanner)
Z+F Imager 5016 (3D laser scanner)
Leica HDS 6000 series (3D laser scanner)
Leica HDS 7000 series (3D laser scanner)
■
The supported laser scanners have
different specifications in terms of rotation
speed, distance and angular accuracy,
point resolution, etc.
■
Only the Amberg Profiler 6012 and Z
+F Profiler 9012 are compatible with IMS
5000.
■
Please read the corresponding product
documentation and user manual
Page 16 of 114 © Amberg Technologies AG, 2023
