WORKSHOP MANUAL
List of harness wires / N1 connector
No.
Cross-
section
Colour from Pin to Pin Note
101 2.5 white N1 1 F11 1 Control 12V
102 2.5 white N1 2 F12 2 Control 12V
103 2.5 brown N1 3 Casing - back Casing - control
104 2.5 brown N1 4 Casing - back Casing - control
105 0.75 white N1 5 K1 86 Ignition relay
106 0.75 white N1 6 S1 19 9 Preheating relay
107 0.75 white N1 7 S1 50 7 Ignition relay
108 1 white N1 8 S25 1 Holding coil
109 0.75 white N1 9 K5 86 Accelerator relay
110 1 white N1 10 Y3 1 Forward
111 1 white N1 11 Y4 1 Reverse
112 1 white N1 12 Y3 2 Return line
113 1 white N1 13 Y5 1 Steering to the left
114 1 white N1 14 Y6 1 Steering to the right
115 1 white N1 15 Y7 1 high amplitude
116 1 white N1 16 Y8 1 low amplitude
117 1 white N1 17 Y9 1 Brake valve
118 0.75 white N1 19 K2 85 Engine signal
120 0.75 white N1 21 N2 4 Safety bar
121 0.75 white N1 22 N2 2 Error
122 0.5 white N1 23 X1 1 Control bus D+
123 0.5 white N1 24 X1 2 Control bus D-
124 1 white N1 25 X1 3 +V12
125 1 brown N1 26 X1 4 Casing
126 0.5 white N1 27 N2 5 Engine oil pressure
127 0.75 white N1 28 S24 1 Safety bar
128 0.5 white N1 29 N2 6 Water temperature
129 1 white N2 1 F13 3 +12 V
130 0.5 white N2 3 S1 19 8
Preheating indicator
lamp
131 0.5 white N2 5 S21
Oil pressure indicator
lamp
132 0.5 white N2 6 S22 1 Water temperature
133 0.5 white N2 7 K2 85 Engine signal
134 2.5 white K1 30 S1 15 5
Ignition
135 2.5 white K1 87 F14 D Ignition
136 2.5 white K1 87 X3 2 Ignition
137 0.75 brown K1 85 Casing - back Ignition relay
138 4 white K2 30 M1 30 Battery 12V
139 0.75 white K2 86 S1 50 7 Starter
140 2.5 white K2 87 M1 50 Starter
141 1.5 white K2 87 F21 A Input coil
142 0.75 white K2 85 G1 D+ 1 Ignition lock
143 0.75 white K3 red F21 1 Timer
144 0.75 brown K3 black Casing - engine Timer
145 0.75 white K3 red/black K4 86 Timer
146 0.75 white K3 yellow K4 85 Timer
