6 Cab and platform
No.
Cross-
section
Colour from Pin to Pin Note
147 1.5 white K4 30 F21 1 Input relay
148 1.5 white K4 87 Y1 white Input coil
149 0.75 brown K5 85 Casing - engine Accelerator relay
150 1.5 white K5 30 F23 3 Accelerator magnet
151 1.5 white K5 87 Y2 + Accelerator magnet
152 0.75 white K6 86 S1 19 9 Preheating relay
153 0.75 brown K6 85 Casing - engine Preheating relay
154 4 white K6 30 F24 4 Preheating
155 4 white K6 87 R1 Preheating
156 0.75 white K7 86 S25 2 Cooler relay
157 0.75 brown K7 85 Casing - back Cooler relay
158 2.5 white K7 30 F14 4 Oil cooler
159 2.5 white K7 87 M3 1 Oil cooler
160 0.75 white S24 2 S24 3 Safety bar
161 0.75 white S24 4 F13 3 Safety bar
162 4 white G1 30 M1 30 Charging current
163 0.75 white G1 15
2 F22 2 Exciter voltage
164 0.75 white M2 F22 2 Diesel fuel pump
165 1 brown M2 Casing - engine Diesel fuel pump
166 1.5 brown Y1 black Casing - engine Holding coil
167 1 white Y3 2 Y4 2 Return line
169 1 brown Y5 2 Casing - engine Steering to the left
170 1 brown Y6 2 Casing - engine Steering to the right
171 1 brown Y7 2 Casing - engine high amplitude
172 1 brown Y8 2 Casing - engine low amplitude
173 1 brown Y9 2 Casing - engine Brake valve
174 1.5 brown Y2 Casing - engine Accelerator magnet
175 1 brown N2 8 Casing - back Display unit
176 2.5 brown M3 2 Casing - back Oil cooler
177 1.5 white F13 C F14 D Display unit
178 2.5 white F12 B S1 15 6 Control 12V
179 1 white F12 B F11 A Control 12V
180 4 white M1 30 S1 30 1 +12 V
181 4 white M1 30 F24 D Preheating
182 1.5 white M1 30 F23 C Accelerator magnet
183 4 brown Casing - engine Casing - back Connection
184 4 brown Casing - engine Casing - front Connection
185 1 white S25 1 Y1 red Holding coil
186 1 white X3 2 F22 B Ignition
187 1 white F21 A X3 1 Starter
188 1.5 white M1 30 X3 3 Battery +
189 2.5 brown X3 4 Casing - engine 2. Holding coil Y11
