123ARR1575
WORKSHOP MANUAL
Drum, rear right
Drum hose, rear right
No. from to
51 Travel circuit A reverse Interface, rear
53 Travel motor brake rear right Interface, rear
55 Travel circuit B forward Interface, rear
57 Leaked oil – return ow Hydraulic oil tank – return ow
58 Travel motor brake, rear right – L neck Travel motor brake, rear left
59 Leaked oil – travel motor, rear right – L neck Leaked oil – travel motor, rear left – L neck
