Ammann ARR 1575 - Page 146

To Next Page

To Previous Page

144 ARR1575

557D332

557D333

557D334

557D335

7 Front drum

Mount the pulling tool here (arrow).

Remove the outer bearing rings and the spacer ring.

Clean the bearing housing.
